Filter tube automatic sewing production line

FOB Reference Price:Get Latest Price
US $20,000-50,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
10 Set/Sets per Month
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland), Jiangsu, China (Mainland)
Brand Name:
SFF, SFF
Model Number:
sff-001, SFF ATS
Condition:
New
After-sales Service Provided:
Engineers available to service machinery overseas
Material Of Bag:
Polyester
Type:
Pocket Filter
Usage:
Dust Filter
Packaging & Delivery
Packaging Details
container loading
Delivery Time
15-20days after the payment
Automatic filter bag& tube sewing line/filter cloth/filter felt

SFFiltech offered the automatic tubing sewing line is the special sewing machine for the filter bag tube, it has the good performance of continuously production, high effective, low labor intensity, low cost of maintenance, which is special design for the needle punched filter bag fabricated mills.
The size of the machine:  17m*1.54m*1.95m
The weight of the machine: 650KG
The sewing running speed: >7m/mins


Other instruction:
1.     The whole line is controlled by electrical, no need for the air compressor additional plus.
2.     The length of the bag is controlled by the photoelectric switch, which has the very fast reaction, the tolerance of the bag length is +/-2mm
3.     The main sewing parts is used the famous brand35800DRU, which can run stabilization, auto lubricated, the needle gage is 3.2/3.2mm, and it can be adjusted.
4.     The feeding, storing, cutting, and unloading all running automatic, without manual work.
5.     The consumer can choose if you need to install the cooling device (water cooler or oil cooler).



We supply: automatic filter bag tubing sewing line, hot melting sewing machine, machine for cutting the non woven material, liquid filter bag making machine, long arm and short arm sewing machine and etc.



To talk more, please contact with via email or call me.
